Huvitz HAB-8000 Lens Tracer and Blocker

Rated 5.00 out of 5 based on 2 customer ratings

$6,900

The Huvitz HAB-8000 is a one-stop solution, combining the functions of a tracer, lensmeter, and blocker in one powerful machine. Simply place the lens in position and the HAB-8000 will do the rest.
The HAB-8000 is user-friendly enough for in-office use as well as robust enough for higher-volume settings. In fact, with the HAB-8000 you can process up to four jobs at the same time while connecting to up two separate edgers and a drill unit. The possibilities are endless. A 10.4-inch high-resolution touch screen monitor allows operators to control all of the system’s functions. Featuring Automatic Lens Center Recognition, the HAB-8000 automatically detects the lens shape and knows what type of lens you’re using. The integrated high-performance lensmeter automatically recognizes the lens as it is set in position. Whether it’s a progressive, bi-focal, or other lens, there’s no need for marking with the HAB-8000. In addition, this high-end Huvitz model offers Digital Scan Hole Detection, Advanced 3D Tracing, Drag-and-Drop Hole Editing, Real-Time Data Transmission and so much more. Fully automated lens centering and blocking is now available at the push of a button.

Category: Patternless Edgers Tag: Huvitz HAB-8000 Lens Tracer and Blocker

Description
Reviews (2)

Description

Tracing Type	Automatic 3D Binocular Tracing

Tracing Mode	Auto, Semi-Auto

Tracing Size	Frame ø0.62~3.62in (16.0~92.0mm), pattern ø0.62~3.30in (16.0~84.0mm)

Frame Material	Metal, Hard Plastic, Soft Plastic

Data Processing	FPD, Frame Curve, Circumference, 3D Angle Concave Shape

Lensmeter Camera	CMOS B/W 1.3M

Imaging Camera	CMOS B/W 1.3M 2x Image

Measurement	SPH: -10D ~ +10D, CYL : -6D ~ +6D

Increment	0.01D

Blocking Tolerance	-0.01 ~ +0.01in (-0.5 ~ +0.5mm)

Axis Tolerance	-1° ~ +1°

Blocking Method	Automatic Blocking with Mechanical Arm

Blocking PRessure	3.0 kgf

Lens Recognition Mode	Intelligent, Auto, Manual

Lens Type Recognition	Single, Bi-focal, Progressive, 3-Dot

Layout Factors	FPD, PD(Binocular, Monocular), Cyl Axis, Bridge Size, OH(△Y, Mixed Height, Box Height), Centering Method(Box Center, Optical Center)

Edging Factors	Plastic, Poly Carbonate, High Index Plastic, Glass, Trivex, Bevel, Groove, Flat Edge, Polish, Safety Bevel

Functions	Job Manager, Digital Pattern, Hole Editor, Digital Scanning(Shape&Hole Recognition)

Utilities	LCD Tilting, SD Card Storage(Memory included), Bar Code Reader(Optional)

Display	10.4 Inch TFT Color TFT LCD(1024×768) with Touch Screen

Edging Size	Maximum 3.54in (90mm), Minimum 0.71in (18mm) – Flat Edging : 0.73in (18.5mm)(without safety Bevel) -Bevel Edging : 0.79in (20mm) (without safety Bevel)

Dimensions / Weight	11.82(W) x 18.50(D) x 22.05(H) in (300(W) x 470(D) x 560(H)mm) / 50.60lb (23kg)

Power Supply	AC 100 – 240V, 50 / 60Hz

Power Consumption	75W
